ASRock 4Core1600P35-WiFi+ / 4Core1600P35-WiFi Motherboard

EnglishEnglish

English

CAUTION!

1. FSB1600-CPU will operate in overclocking mode. If you use a FSB1600-

CPU on this motherboard, you need to adjust the jumpers. Please refer

to page 25 for proper jumper settings. Besides, if you want to change a

new CPU on this motherboard, please remove the AC power cord from

your PC in advance.

2. About the setting of “Hyper Threading Technology”, please check page

56 of “User Manual“ in the support CD.

3. This motherboard supports Untied Overclocking Technology. Please read

“Untied Overclocking Technology” on page 47 for details.

4. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read

the installation guide of memory modules on page 16 for proper

installation.

5. Please check the table below for the CPU FSB frequency and its

corresponding memory support frequency.

CPU FSB Frequency Memory Support Frequency

1600 DDR2 800, DDR2 1066,

DDR3 1066, DDR3 1333

1333 DDR2 667, DDR2 800, DDR2 1066,

DDR3 800, DDR3 1066, DDR3 1333

1066 DDR2 667, DDR2 800, DDR2 1066,

DDR3 800, DDR3 1066

800 DDR2 667, DDR2 800,

DDR3 800

* DDR2 1066 and DDR3 1333 memory modules will operate in

overclocking mode.

* When you use a FSB1600-CPU on this motherboard, it will run at

DDR2 960 if you adopt a DDR2 1066 memory module. When you

use a FSB1600-CPU on this motherboard, it will run at DDR3 960

if you adopt a DDR3 1066 memory module. When you use a

FSB1600-CPU on this motherboard, it will run at DDR3 1280 if you

adopt a DDR3 1333 memory module.

* If you adopt a DDR2 1066 memory module and adopt a FSB1333-

CPU or FSB1066-CPU on this motherboard, you need to adjust the

jumpers. Please refer to page 25 for proper jumper settings.

6. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows

and Windows

Vista

. For Windows

XP 64-bit and Windows

Vista

64-bit with 64-bit CPU, there is no such limitation.

7. DTS (Digital Theater Systems) is a multi-channel digital surround sound

format. To enable DTS function, you need to adjust the settings after

audio driver installation. Please refer to “DTS Operation Guide” on page

45 for details.

8. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-

channel, 6-channel, and 8-channel modes. Please check the table on

page 4 and 5 for proper connection.
