1.4 Motherboard Layout1.4 Motherboard Layout
1.4 Motherboard Layout1.4 Motherboard Layout
1.4 Motherboard Layout
1
PS2_USB_PWR1
ATXPWR1
ConRoe1333-1394
IDE1
7.1CH HD
USB2.0
CHA_FAN1
USB6_7
1
SPEAKER1
1
HD_AUDIO1
Intel
945GC A2
Chipset
IR1
1
CLRCMOS1
PANEL1
HDLED RESET
PLED PWRBTN
1
CMOS
Battery
USB4_5
1
4Mb
BIOS
CPU_FAN1
1
AUDIO
CODEC
24.4cm (9.6 in)
24.4cm (9.6 in)
ATX12V1
Top:
SIDE SPK
Center:
REAR SPK
Bottom:
CTR BASS
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
USB 2.0
T: US B0
B: USB1
Top:
RJ-45
PARALLEL PORT
COM1
PS2
Mouse
PS2
Keyboard
Super
IO
Dual Channel
DDRII667
SATAII
FLOPPY1
1
2
4
5
7
6
8
9
10
12
13
14
11
15
16
17
18
1922
23
24
25
26
28
27
3
20
21
29
FSB1333
Dual Core CPU
Presler
Conroe
RoHS
Intel
ICH7
FSB800
DDRII_1 (64/72 bit, 240-pin module)
DDRII_2 (64/72 bit, 240-pin module)
FSB800
DDRII_3 (64/72 bit, 240-pin module)
DDRII_4 (64/72 bit, 240-pin module)
SATAII_4
SATAII_3
SATAII_2
SATAII_1
PCI1
PCI2
PCIE1
PCIE2
CD1
LAN
PHY
PCI
EXPRESS
Gigabit LAN
USB 2.0
T: U SB 2
B: USB3
Top:
1394
1
HDMI_SPDIF1
FRONT_1394
1
30
1 PS2_USB_PWR1 Jumper 16 Primary SATAII Connector (SATAII_1; Red)
2 ATX 12V Connector (ATX12V1) 17 Chassis Fan Connector (CHA_FAN1)
3 CPU Fan Connector (CPU_FAN1) 18 USB 2.0 Header (USB6_7, Blue)
4 775-Pin CPU Socket 19 USB 2.0 Header (USB4_5, Blue)
5 North Bridge Controller 20 Floppy Connector (FLOPPY1)
6 Clear CMOS Jumper (CLRCMOS1) 21 Front Panel Audio Header (HD_AUDIO1)
7 2 x 240-pin DDRII DIMM Slots 22 Internal Audio Connector: CD1 (Black)
(Dual Channel A: DDRII_1, DDRII_3; Yellow) 23 HDMI_SPDIF Header (HDMI_SPDIF1; Yellow)
8 2 x 240-pin DDRII DIMM Slots 24 PCI Slots (PCI1- 2)
(Dual Channel B: DDRII_2, DDRII_4; Orange) 25 Front Panel IEEE 1394 Header
9 South Bridge Controller (FRONT_1394; Red)
10 IDE1 Connector (IDE1, Blue) 26 PCI Express x1 Slot (PCIE2)
11 Chassis Speaker Header (SPEAKER 1) 27 PCI Express x16 Slot (PCIE1)
12 System Panel Header (PANEL1) 28 ATX Power Connector (ATXPWR1)
13 Fourth SATAII Connector (SATAII_4; Orange) 29 BIOS FWH Chip
14 Secondary SATAII Connector (SATAII_2; Red) 30 Infrared Module Header (IR1)
15 Third SATAII Connector (SATAII_3; Orange)
