ASRock N68-GS4/USB3 FX R2.0 / N68-GS4 FX R2.0 Motherboard
DeutschDeutsch
DeutschDeutsch
Deutsch
- Unterstutzt energieeffizientes Ethernet 80
- Unterstützt PXE
E/A-Anschlüsse N68-GS4/USB3 FX R2.0:
an der - 1 x PS/2-Mausanschluss
Rückseite - 1 x PS/2-Tastaturanschluss
- 1 x Serieller port: COM1
- 1 x D-Sub port
- 2 x Standard-USB 2.0-Anschlüsse (unterstutzt Schutz gegen
elektrostatische Entladung (ASRock Full Spike Protection))
- 2 x Standard-USB 3.0-Anschlüsse (Etron EJ188H) (PCIE GEN1)
(unterstutzt Schutz gegen elektrostatische Entladung (ASRock
Full Spike Protection))
- 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED LED)
- HD Audiobuchse: Audioeingang / Lautsprecher vorne /
Mikrofon
E/A-Anschlüsse N68-GS4 FX R2.0:
an der - 1 x PS/2-Mausanschluss
Rückseite - 1 x PS/2-Tastaturanschluss
- 1 x Serieller port: COM1
- 1 x D-Sub port
- 4 x Standard-USB 2.0-Anschlüsse (unterstutzt Schutz gegen
elektrostatische Entladung (ASRock Full Spike Protection))
- 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED LED)
- HD Audiobuchse: Audioeingang / Lautsprecher vorne /
Mikrofon
Speicher - 4 x SATA2-Anschlüsse, unterstützt bis 3.0 Gb/s
Datenübertragungsrate, unterstützt RAID (RAID 0, RAID 1,
RAID 0+1, RAID 5, JBOD), NCQ und “Hot Plug” Funktionen
Anschlüsse - 1 x Druckerport-Anschlussleiste
- 1 x Verteiler fur Gehauseeindringversuche
- 1 x CPU-Lüfteranschluss (4-polig)
- 1 x Gehäuse-Lüfteranschluss (3-polig)
- 1 x 24-pin ATX-Netz-Header
- 1 x 8-pin anschluss für 12V-ATX-Netzteil
- 1 x Anschluss für Audio auf der Gehäusevorderseite
- 2 x USB 2.0-Anschlüsse (Unterstützung 4 zusätzlicher
USB 2.0-Anschlüsse) (unterstutzt Schutz gegen
elektrostatische Entladung (ASRock Full Spike Protection))
- 1 x Etron EJ188H USB 3.0-Anschlüsse (PCIE GEN1)
(Unterstützung 2 zusätzlicher USB 3.0-Anschlüsse) (unterstutzt
Schutz gegen elektrostatische Entladung (ASRock Full Spike
Protection)) (N68-GS4/USB3 FX R2.0)
