MEAN WELL ELGC-300-H-A Data Sheet онлайн
300W Constant Power Mode LED Driver
ELGC-300 series
File Name:ELGC-300-SPEC 2018-09-30
■ Description
LED bay lighting
LED stage lighting
LED spot lighting
LED fishing lighting
LED horticulture lighting
Stadium lighting
■ Features
■ Applications
Full power at 65~100% max current (Constant Power )
Built-in active PFC function
IP67 design for indoor or outdoor installations
Function options: output adjustable via potentiometer;
3 in 1 dimming (dim-to-off) ; DALI dimming
Typical lifetime>50000 hours
5 years warranty
■ Model Encoding
L
ELGC - 300
Rated output current(1400/2800/5600mA)
Rated wattage
Series name
Function options
ELGC-300 series is a 300W LED AC/DC driver featuring the constant power mode and high voltage
output. ELGC-300 operates from 100~305VAC and offers models with different rated current ranging
between 1300mA and 8000mA. Thanks to the high efficiency up to 94.5%, with the fanless design, the
entire series is able to operate for -40 ~+85 case temperature under free air convection. The design
℃℃
of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor
applications. Moreover the innovative environment-adaptive capability allows this series to reliably light
on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires
in the world. ELGC-300 is equipped with various function options, such as dimming methodologies, so as
to provide the optimal design flexibility for LED lighting system.
AB
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
IP67
In Stock
Type
FunctionIP Level
A
DA DALI control technology.
IP67
IP67
Note
In Stock
D2 IP67
By request
Built-in Smart timer dimming and programmable function.
output constant power adjustable via built-in potentiometer
output constant power adjustable via built-in potentiometer +
In Stock
110
SELV
IP67
--
05
(for H/M Type)
A
