BLOCK DIAGRAM
PFC fosc : 45KHz
PWM fosc : 100KHz
300W Constant Power Mode LED Driver
ELGC-300 series
File Name:ELGC-300-SPEC 2018-09-30
DIM+
DIM-
(AB Type)
DETECTION
PWM
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.C.P.
PFC
CIRCUIT
PFC
CONTROL
DRIVING METHODS OF LED MODULE
※-I V Operating Area
◎ ELGC-300-L
230VAC
110VAC
230VAC
110VAC
O.T.P.
1300mA, 116V
2600mA, 116V
2600mA, 58V
2210mA, 116V
3400mA, 58V
50V
60V
70V
80V
90V
100V
110V
120V
0mA 550mA 1100mA 1650mA 2200mA 2750mA 3300mA 3850mA 4400mA
◎ ELGC-300-M
3400mA,75.4V
◎ ELGC-300-H
2600mA, 58V
5200mA, 29V
4420mA, 58V
6800mA, 29V
25V
30V
35V
40V
45V
50V
55V
60V
0mA 1100mA 2200mA 3300mA 4400mA 5500mA 6600mA 7700mA 8800mA
6800mA,37.7V
230VAC
110VAC
230VAC
110VAC
650mA, 232V
1300mA, 116V
1105mA, 232V
1700mA, 116V
100V
120V
140V
160V
180V
200V
220V
240V
0mA 300mA 600mA 900mA 1200mA 1500mA 1800mA 2100mA
1700mA,150.8V
230VAC
110VAC
1300mA,232V
2000mA,116V
2000mA,150.8V
4000mA,58V
4000mA,75.4V
8000mA,29V
8000mA,37.7V
5200mA,58V
