MEAN WELL ELGC-300-H-A [10/10] Elgc 30
![MEAN WELL ELGC-300-H-A [10/10] Elgc 30](/views2/1691513/page10/bga.png)
300W Constant Power Mode LED Driver
ELGC-300 series
File Name:ELGC-300-SPEC 2018-09-30
INSTALLATION MANUAL
※ DA/D2-Type
39.5
36
86
tc
* DA+ for DA Type
PROG+ for D2 Type
* *DA- for DA Type
PROG- for D2 Type
235
246
222
300±20
300±20
DA-/PROG-(White)**
DA+/PROG+(Blue)*
53.8
77
4- 4.5ψ
SJOW 17AWGx3C
&H05RN-F 3 1.0mm×
2
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
&H05RN-F 2 1.0mm×
2
UL2517 20AWG*2C
: Max. Case Temperature
tc
AC/L(Brown)
AC/N(Blue)
FG (Green/Yellow)
