1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
1 PS2_USB_PW1 Jumper 19 Chassis Speaker Header
2 ATX 12V Power Connector (ATX12V1) (SPEAKER 1, Purple)
3 CPU Heatsink Retention Module 20 NB Fan Connector (NB_FAN1)
4 AM2 940-Pin CPU Socket 21 System Panel Header (PANEL1, Orange)
5 2 x 240-pin DDR2 DIMM Slots 22 Serial Port Connector (COM1)
(Dual Channel A: DDRII_1, DDRII_2; Yellow) 23 Floppy Connector (FLOPPY1)
6 2 x 240-pin DDR2 DIMM Slots 24 Front Panel Audio Header
(Dual Channel B: DDRII_3, DDRII_4; Orange) (HD_AUDIO1, Lime)
7 ATX Power Connector (ATXPWR1) 25 HDMI_SPDIF Header
8 Primary IDE Connector (IDE1, Blue) (HDMI_SPDIF1, Yellow)
9 NVIDIA nForce 720D Chipset 26 PCI Slots (PCI1- 3)
10 SATAII Connector (SATAII_6 (PORT 5), Red) 27 Internal Audio Connector: CD1 (Black)
11 SATAII Connector (SATAII_5 (PORT 4), Red) 28 SPI BIOS Chip
12 SATAII Connector (SATAII_4 (PORT 3), Red) 29 PCI Express x1 Slot (PCIE4, White)
13 SATAII Connector (SATAII_3 (PORT 2), Red) 30 Clear CMOS Jumper (CLRCMOS1)
14 SATAII Connector (SATAII_2 (PORT 1), Red) 31 PCI Express x1 Slot (PCIE3, White)
15 SATAII Connector (SATAII_1 (PORT 0), Red) 32 PCI Express x16 Slot (PCIE2, Green)
16 USB 2.0 Header (USB6_7, Blue) 33 PCI Express x1 Slot (PCIE1, White)
17 USB 2.0 Header (USB10_11, Blue) 34 Chassis Fan Connector (CHA_FAN1)
18 USB 2.0 Header (USB8_9, Blue) 35 CPU Fan Connector (CPU_FAN1)
Super
I/O
CMOS
BATTERY
ATXPWR1
SOCKET AM2
CD1
NVIDIA
nForce 720D
Chipset
PS2_USB_PW1
1
IDE1
FSB800
DDRII_1 (64 bit, 240-pin module)
DDRII_2 (64 bit, 240-pin module)
FSB800
DDRII_3 (64 bit, 240-pin module)
DDRII_4 (64 bit, 240-pin module)
PCI1
AUDIO
CODEC
1
CLRCMOS1
CPU_FAN1
HDLED RESET
PLED PWRBTN
1
PANE L 1
NB_FAN1
SPEAKER1
1
FLOPPY1
HD_AUDIO1
1
RoHS
30.5cm (12.0-in)
19.1cm (7.5-in)
6
7
1
2
4
3
5
8
9
10
11
12
13
14
15
16
17
18
1920
21
22
23
24
25
26
27
28
PCIE1
1
HDMI_SPDIF1
29
8Mb
BIOS
SATAII_1(PORT 0)
DDR2 1066
FSB2.6GHz
HT3.0
PCI Express 2.0
PCI2
USB8_9
1
30
31
32
33
PCI3
K10N78D
COM1
1
34
LAN
PHY
Top:
SIDE SPK
Center:
REAR SPK
Bottom:
CTR BASS
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
PS2
Mouse
PS2
Keyboard
USB 2.0
T: USB 0
B: USB1
Top:
RJ-45
Coaxial
SPDIF
Optical
SPDIF
USB 2.0
T:USB4
B: USB5
USB 2.0
T:USB2
B: USB3
ATX12V1
USB10_11
1
USB6_7
1
SATAII_2(PORT 1)
SATAII_3(PORT 2)
SATAII_4(PORT 3)
SATAII_5(PORT 4)
SATAII_6(PORT 5)
CHA_FAN1
PCIE2
PCIE3
PCIE4
Dual Channel
Phenom II
AM2+/AM3
35
