3838
3838
38
Secure Virtual Machine
When this option is set to [Enabled], a VMM (Virtual Machine Architecture)
can utilize the additional hardware capabilities provided by AMD-V. The
default value is [Enabled]. Configuration options: [Enabled] and [Disabled].
Enhanced Halt State
C1E is an enhanced power saving state which is supported by AM2 dual core
and AM2+ multi-core processors. The processor will enter C1E power saving
state when both of its cores transition into the C1 state. The default value is
[Disabled]. Configuration options: [Enabled] and [Disabled].
L3 Cache Allocation
This option appears only when you adopt Phenom CPU. The default value
is [Auto]. Configuration options: [Auto], [BSP Only] and [All Cores].
Processor Maximum Frequency
It will display Processor Maximum Frequency for reference.
North Bridge Maximum Frequency
This option appears only when you adopt Phenom CPU. It will display North
Bridge Maximum Frequency for reference.
Processor Maximum Voltage
It will display Processor Maximum Voltage for reference.
Multiplier/Voltage Change
This item is set to [Auto] by default. If it is set to [Manual], you may adjust the
value of Processor Frequency and Processor Voltage. However, it is recom-
mended to keep the default value for system stability.
BIOS SETUP UTILITY
CPU Configuration
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
CPU/LDT Spread Spectrum
SATA
Cool'n'Quiet
Secure Virtual Machine
Enhanced Halt State
L3 Cache Allocation
Spread Spectrum
Boot Failure Guard
Processor Maximum Frequency
North Bridge Maximum Voltage
Processor Maximum Voltage
x11.5 2300 MHz
x9.0 1800 MHZ
1.2500 V
[Enabled]
[Enabled]
[Enabled]
[Auto]
[Enabled]
[Disabled]
[Auto]
Multiplier/Voltage Change
[Manual]
If AUTO, multiplier and
voltage will be left at the
rated frequency/voltage. If
Manual,
will be set based
on User Selection in Setup.
multiplier and
voltage
CPU Frequency Multiplier
CPU Voltage
[x11.5 2300 MHZ]
[1.2500 V]
Processor Frequency
This option appears only when you adopt AM2 CPU. This item will show when
“Multiplier/Voltage Change” is set to [Manual]; otherwise, it will be hidden. The
range of the value depends on the CPU you adopt on this motherboard. However,
for system stability, it is not recommended to adjust the value of this item.
