ASRock ALiveNF6G-GLAN Motherboard

2.9 Serial A2.9 Serial A

2.9 Serial A

A (SAA (SA

A (SA

A) / Serial AA) / Serial A

A) / Serial A

AII (SAAII (SA

AII (SA

AII) Hard DisksAII) Hard Disks

AII) Hard Disks

Installation Installation

Installation

This motherboard adopts NVIDIA

GeForce 6150SE / nForce 430 chipset that

supports Serial ATA (SATA) / Serial ATAII (SATAII) hard disks and RAID functions. You

may install SATA / SATAII hard disks on this motherboard for internal storage devices.

This section will guide you to install the SATA / SATAII hard disks.

STEP 1: Install the SATA / SATAII hard disks into the drive bays of your chassis.

STEP 2: Connect the SATA power cable to the SATA / SATAII hard disk.

STEP 3: Connect one end of the SATA data cable to the motherboard’s SATAII

connector.

STEP 4: Connect the other end of the SATA data cable to the SATA / SATAII hard

disk.

2.102.10

2.10

Hot Plug and Hot Swap FHot Plug and Hot Swap F

Hot Plug and Hot Swap F

unctions for SAunctions for SA

unctions for SA

A / SAA / SA

A / SA

AIIAII

AII

HDDsHDDs

HDDs

This motherboard supports Hot Plug and Hot Swap functions for SATA / SATAII

Devices.

NOTE

What is Hot Plug Function?

If the SATA / SATAII HDDs are NOT set for RAID configuration, it is

called “Hot Plug” for the action to insert and remove the SATA / SATAII

HDDs while the system is still power-on and in working condition.

However, please note that it cannot perform Hot Plug if the OS has

been installed into the SATA / SATAII HDD.

What is Hot Swap Function?

If SATA / SATAII HDDs are built as RAID1 then it is called “Hot Swap”

for the action to insert and remove the SATA / SATAII HDDs while the

system is still power-on and in working condition.

EnglishEnglish

English
