ASRock U-COP: Dual External/Internal temperature sensor

Hardware mechanism

CPU overheat shutdown to protect CPU life

Supports all socket A AMD CPU, Athlon

/ Athlon

XP/

Duron

Hardware Monitor: Voltage monitoring: +12V, +5V, +3V, Vcore

CPU fan tachometer

Chassis fan tachometer

PCI slots: 3 slots with PCI Specification 2.2

AGP slot: 1 universal AGP slot, supports 3.3v / 1.5v, 4X / 2X / 1X AGP

card

AMR slot: 1 slot, supports ASRock AMR modem card, shares the

bracket with the slot PCI 3

USB 2.0: 4 default USB ports and a set of header for two additional

USB ports upgrade

ASRock I/O

: PS/2: 1 keyboard port / 1 mouse port

1 RJ 45 port

4 rear default USB ports (USB 2.0)

1 VGA port

1 Parallel port, supports ECP/EPP

Audio Jack: Line Out/ Line In/ Microphone + Game port

BIOS: AMI legal BIOS

Supports “Plug and Play”

ACPI 1.1 compliance wake up events

Supports jumperfree

SMBIOS 3.0 support

CPU frequency stepless control

(only for advanced users’ reference)

OS: Windows 98SE / ME / 2000 / XP compliant

1. While CPU overheat is detected, the system will automatically

shutdown and the power button on the chassis will be disabled.

Please check if the CPU fan on the motherboard functions

properly before you resume the system.

2. Although K7VM2 offers stepless control, it is not recommended

to perform over clocking. Frequencies other than the

recommended CPU bus frequencies may cause the instability of

the system or damage the CPU.
