22
Appendix: Advanced BIOS Setup
This section will introduce you the following BIOS Setup menus: “Advanced,”
“Security,” “Power,” “Boot,” and “Exit.”
1. Advanced BIOS Setup Menu
Spread Spectrum:
This field should always be [Disabled] for better system stability.
CPU Host Frequency:
[Auto]: It is recommended to select this option, which will let the CPU host
frequency of this motherboard determined by the jumper-setting.
[Manual]: This allows user to set CPU host frequency manually. However,
because the CPU host frequency of this motherboard is determined by the
jumper-setting, you must set the FSB jumper adjustment according to your
AMD CPU before you use this “Manual” option as the FSB setting in BIOS
setup to perform over clocking. This is not recommended unless you
thoroughly know the feature. Wrong setup may cause problems during
operation.
DRAM Frequency:
If set to [Auto], the motherboard will detect the inserted memory module(s) and
automatically assign appropriate frequency. You may select other value as
operating frequency: [100MHz (DDR200)], [133MHz (DDR266)],
[166MHz (DDR333)], [200MHz (DDR400)]. Please note that the option
[200MHz (DDR400)] will be available only when one DIMM is installed.
AMIBIOS SETUP UTILITY - VERSION 3.31a
Main
Advanced
Security
Power
Boot
Exit
Spread Spectrum
CPU Host Frequency
Actual Frequency
DRAM Frequency
Chipset Configuration
Resource
Peripheral
System Hardware Monitor
Configuration
Configuration
[ Setup Help ]
Auto
133MHz
Auto
<Enter> to enable or
disable the feature of
spread spectrum.
F1:Help
Esc:Exit
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
:Select Menu
Disabled
