ASRock Vision HT Series [11/63] English
![ASRock Vision HT Series [11/63] English](/views2/1692980/page11/bgb.png)
4
English
VGA resolution
:
Display 1 Display 2
Maximum Resolution
Display 1
Maximum Resolution
Display 2
HDMI DVI
4096x2304 @ 24Hz
2560x1600 @ 60Hz
1920x1200 @ 60Hz
VGA HDMI 1920x1200 @ 60Hz
4096x2304 @ 24Hz
2560x1600 @ 60Hz
