ASRock Vision HT Series [21/63] Chapter 4 installing the second hdd
![ASRock Vision HT Series [21/63] Chapter 4 installing the second hdd](/views2/1692980/page21/bg15.png)
14
English
Chapter 4 Installing the second HDD
1. Please follow steps 1 to 3 on page 15 to remove the ODD and the rst HDD in
advance. en install the second HDD and fasten the screws to the rack.
2. Place the rst HDD to the rack and fasten the screws from both sides.
3. Place the ODD to the rack and fasten the screws from both sides. Replace the rack
into the chassis.
