WARNING

Please realize that there is a certain risk involved with over-

clocking, including adjusting the setting in the BIOS, applying

Untied Overclocking Technology, or using third-party overclock-

ing tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your

system. It should be done at your own risk and expense. We are

not responsible for possible damage caused by overclocking.
