1.3 Motherboard Layout
1. SATA 3.0 connector: For the HDD’s SATA data cable
2. Heatsink
3. Fan connector
4. Fan connector
5. Memory sockets
6. Infrared module header
7. CPU Fan
8. Mini-PCI Express expansion slot: For the WiFi module
9. Clear CMOS jumper
10. SATA 3.0 connector: For the ODD’s SATA data cable
11. ATX5V output power connector for slim ODD & 2.5” HDD
12. SATA 3.0 connector: For the HDD’s SATA data cable
