17. DC-In jack
18. Optical S/PDIF Out port
19. Mic In (Pink): Microphone
20. Front L/R Out (Lime): Stereo speakers or headphones
21. HDMI connector
22. Powered eSATA/USB connector
23. Display (VGA) port
24. USB2.0 ports: USB devices
25. LAN (RJ-45) port: Local Area Network
26. Line In (Blue) for 2/4/6 channel; Rear (Blue) for 8 channel
27. Center/LFE (Orange): Center / subwoofer speakers
28. Side port for side speakers
