1.6 Internal System Components1.6 Internal System Components
1.6 Internal System Components1.6 Internal System Components
1.6 Internal System Components
Optical disc & Hard disk drives
The optical disc and hard disc drives are mounted in a drive cage. The
cage can be removed by removing the top screws.
32. System Cooling Fan
33. Optical Disc Drive
34. Hard Disc Drive
32
33
34
