4. Connect one end of SATA and power cables to the ODD and the other
end to the bottom HDD.
5. Connect the other SATA and power cables to SATAII_3 and J1
connectors on the motherboard.
6. Connect the other end to the top HDD.
7. Replace the side cover and fasten the screws.
