1.6 Internal System Components1.6 Internal System Components

1.6 Internal System Components

Optical disc & Hard disk drives

The optical disc and hard disc drives are mounted in a drive cage. The

cage can be removed by removing the top screws.

29. System Cooling Fan

30. Optical Disc Drive

31. Hard Disc Drive
