WARNING
Please realize that there is a certain risk involved with overclocking, including adjusting
the setting in the BIOS, or using the third-party overclocking tools. Overclocking may
affect your system stability, or even cause damage to the components and devices
of your system. It should be done at your own risk and expense. We are not
responsible for possible damage caused by overclocking.
Processor Intel
®
Atom
TM
330 (Dual-Core CPU)
Chipset NVIDIA
®
ION
TM
graphics processor
Memory 2GB DDR2 800MHz, support Dual Channel,
maximun up to 4GB *
VGA NVIDIA
®
ION
TM
Graphics, support DX10 / Full HD 1080p
** (Blu-ray / HD-DVD) playback
HDD 2.5” HDD 320GB
DVD DVD Super Multi or BD combo
(BD-ROM/DVD/CD Rewrite, for ION 330-BD)
I/O 1 x HDMI, 1 x D-Sub VGA, 6 x USB 2.0,
1 x S/PDIF (Optical)
LAN Gigabit LAN
Sound HD Audio 5.1 channel
Power 65W/19V Adapter
Dimension 195mm(W)x70mm(H)x186m(L)
Volume (liters) 2.5L
Weight 1.75 Kg
* Due to the CPU limitation, the actual memory size may be less than 4GB for the
reservation for system usage under Windows
®
XP, Windows
®
XP 64-bit,
Windows
®
Vista
TM
and Windows
®
Vista
TM
64-bit.
** Blu-ray/HD-DVD disc is supported by Blu-ray/HD-DVD drive.
