ASRock ION 330-BD [21/39] 5 5 5 5 installation installation installation installation installation

2121

b. Select destination location. You may choose a different folder if you

need, and click “Next”.

c. Select the start menu folder. You may choose a different folder if you

need, and click “Next”.

5.1.25.1.2

5.1.2

InstallationInstallation

Installation

Please read below procedures carefully before you install Instant Boot.

A. Install Instant Boot driver from ASRock support CD, or you may click

following link to get the latest utility and BIOS:

http://www.asrock.com/feature/InstantBoot/download.asp

B. Execute the Instant Boot installation program under Windows

. Please

follow the instructions on Instant Boot setup page.

a. Click “Next” to continue.
