12
2.3 Installation of Memory Modules (DIMM)
This motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM
slots, and supports Dual Channel Memory Technology.
The DIMM only ts in one correct orientation. It will cause permanent dam-
age to the motherboard and the DIMM if you force the DIMM into the slot at
incorrect orientation.
1.
For dual channel conguration, you always need to install identical (the
same brand, speed, size and chip-type) DDR4 DIMM pairs.
2.
It is unable to activate Dual Channel Memory Technology with only one
memory module installed.
3.
It is not allowed to install a DDR, DDR2 or DDR3 memory module into a
DDR4 slot; otherwise, this motherboard and DIMM may be damaged.
