ASRock IMB-1310 [6/40] Specifications
![ASRock IMB-1310 [6/40] Specifications](/views2/1693096/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Micro ATX (9.6-in x 9.6-in)
Processor
System
CPU
Socket LGA 1151 for 9th/8th Intel
®
Core i7/i5/i3/
Celeron (Supports up to 95W)
* For cooling the CPU exceeding 90W and its
surrounding components, please install a CPU
cooler with a top-down blowing design.
Chipset Intel
®
H310
Expansion
Slot
PCIe 1 x PCIe x16, 1 x PCIe x4
PCI 2
Mini-PCIe N/A
mSATA N/A
M.2
1 x M.2 (Key M, 2242/2260/2280) with SATA3
for SSD
Memory
Technology Dual Channel DDR4 2400/2666MHz
Max.
64GB*
* Intel
®
Core i9/i7/i5 CPUs support up to 64GB
(32GB per DIMM)
Intel
®
Core i3/Pentium
®
/Celeron
®
CPUs
support up to 32GB (16GB per DIMM)
Socket 2 x Long-DIMM
Graphics
VGA
Supports max resolution up to
1920x1200@60Hz
DVI Max resolution up to 1920x1200@60Hz
LVDS
Dual Channel 24-bit, max resolution up to
1920x1200@60Hz
HDMI Max resolution up to 4096x2160@24Hz
DisplayPort Max resolution up to 4096x2304@60Hz
MultiDisplay Dual Display
eDP N/A
Ethernet
Ethernet 10/100/1000 Mbps
Controller 1 x Intel
®
I210, 1 x Intel
®
I219V
Rear I/O
VGA 1
DVI 1
HDMI 1
DisplayPort 1
Ethernet 2
USB 4 x USB support USB3.1
