3.3.7 USB Conguration
Legacy USB Support
Enable or disable Legacy OS Support for USB 2.0 devices. If you encoun-
ter USB compatibility issues it is recommended to disable legacy USB
support. Select UEFI Setup Only to support USB devices under the UEFI
setup and Windows/Linux operating systems only.
USB Power Control
Enable USB power control. This should be enabled for the complete USB
keyboard legacy support for non-USB aware OSesThe default value is
[Default Setting].
