18
Chassis Fan Connector Please connect the fan cable
(3-pin CHA_FAN1)
to the fan connector and
(see p.8 No. 17)
match the black wire to the
ground pin.
CPU Fan Connector Please connect the CPU fan
(4-pin CPU_FAN1)
cable to the connector and
(see p.8 No. 6)
match the black wire to the
ground pin.
Digital Input / Output Pin Header
(10-pin JGPIO1)
(see p.8 No. 21)
GND
+ 12V
CHA_ FAN_ SPEED
GND
+
12V
CPU_ FAN_SPEED
4-pin DC-in PWR Connector
Please connect a
(Input +12V)
DC-in power to this
(4-pin ATX12V1)
connector.
(see p.8 No. 1)
1-4: GND
2-3: DC Input
1
1
LPC Header This connector supports a
(19-pin LPC1)
Trusted Platform Module (TPM)
(
see p.8, No. 16)
system, which can
securely store keys, digital
certicates, passwords, and
data. A TPM system also helps
enhance network security,
protects digital identities, and
ensures platform integrity.
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN Signal Name
2 SIO_GP80 4 SIO_GP81 6 SIO_GP82 8 SIO_GP83 10
GND
1 SIO_GP84 3 SIO_GP85 5 SIO_GP86 7 SIO_GP87 9
JGPIO_PWR
SATA Power Output Connector
(4-pin SATA_PWR1)
(see p.8 No. 2)
G ND
+5V
+12V
1
G ND
