3.3.2 Chipset Conguration

Share Memory

Congure the size of memory that is allocated to the integrated graphics

processor when the system boots up.

Onboard HD Audio

Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature.

Onboard LAN 1

This allows you to enable or disable the Onboard LAN 1 feature.

Onboard LAN 2

This allows you to enable or disable the Onboard LAN 2 feature.

Onboard LAN 3

This allows you to enable or disable the Onboard LAN 3 feature.

Onboard LAN 4

This allows you to enable or disable the Onboard LAN 4 feature.

Deep S5

Mobile platforms support Deep S5 in DC only and desktop platforms sup-

port Deep S5 in AC only. The default value is [Disabled].

Restore on AC/Power Loss

Select the power state after a power failure. If [Power Off] is selected, the

power will remain off when the power recovers. If [Power On] is selected,

the system will start to boot up when the power recovers.
