7
Rear I/O
VGA N/A
DVI N/A
HDMI 1
DisplayPort N/A
Ethernet 4
USB 1 x USB3.1, 3 x USB 2.0
Audio N/A
Serial N/A
PS/2 N/A
Internal
Connector
USB 2 x USB 2.0
LVDS/
Inverter
N/A
eDP N/A
VGA 1 x Header
Serial
COM1, 2 (RS-232/422/485),
COM3, 4, 5, 6 (RS-232)
SATA 1 x SATA2 (3.0Gb/s)
Parallel N/A
GPIO 4 x GPI, 4 x GPO
SATA PWR
Output
1
Speaker
Header
1
TPM TPM Header
Watchdog
Timer
Output From Super I/O to drag RESETCON#
Interval 256 segments, 0,1,2…255sec
Power
Requirements
Input PWR
12V DC-In (with 4-pin wafer PWR cable or
DC Jack)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment
Temperature 0ºC – 60ºC
Storage
Temp
-40ºC – 85ºC
Operating
Humidity
5% ~ 90%
Storage
Humidity
5% ~ 90%
