7
Rear I/O
VGA N/A
DVI N/A
HDMI N/A
DisplayPort 3
Ethernet 2
USB 4 x USB support USB3.1
Audio 2 (Mic-in, Line-out)
Serial N/A
PS2 N/A
Internal
Connector
USB 4 x USB 2.0
LVDS/
inverter
1 (shared with eDP use jumper switch)
eDP 1
VGA N/A
Serial
2 x COM (RS-232/422/485), 2 x
COM(RS-232)
SATA 2 x SATA3 (6.0Gb/s)
GPIO 4 x GPI, 4 x GPO
SATA PWR
Output
1
Speaker
Header
1
TPM 1 x Onboard TPM 2.0 IC
Watchdog
Timer
Output From super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec
Power
Requirements
Input PWR 12V/19~28V 4-pin DC-in
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
ATX: Press Button to PWR on after Power
input ready
Environment
Operating
Temp
0ºC – 60ºC
Storage
Temp
-40ºC – 85ºC
If you use 12V adapter, please be note that the power consumption of 12V
voltage should be under 180W.
