ASRock IMB-1213 [22/42] Dc input
![ASRock IMB-1213 [22/42] Dc input](/views2/1693196/page22/bg16.png)
22
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
2
SIO_
GP20
4
SIO_
GP21
6
SIO_
GP22
8
SIO_
GP23
10
GND
1
SIO_
GP24
3
SIO_
GP25
5
SIO_
GP26
7
SIO_
GP27
9
JGPIO_
PWR
UPS Module Power Input Connector Pin
1 : GND
(2-pin TO_UPS1)
Pin
2 : DC Input
(see p.8 No. 28)
1
Digital Input / Output Pin Header
(10-pin JGPIO1)
(see p.8 No. 8)
