1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA 1151 for 9th/8th Intel
®
Core i7/i5/i3/
Celeron (Supports up to 65W)
* The Performance of CPUs over 65W will be
limited due to power design.
Chipset Intel
®
Q370
Expansion
Slot
PCIe 1 x PCIe x16 (Support riser card)
Mini-PCIe 1 x Full/Half mini-PCIe with PCIe x1 and USB 2.0
mSATA N/A
M.2
1 x M.2 (Key E, 2230) with PCIe x1,
CNVI and USB2.0 for Wireless
1 x M.2 (Key M, 2242/2260/2280)
with PCIe x4 and SATA3 for SSD
Memory
Technology Dual Channel DDR4 2400/2666MHz
Max.
64GB*
* Intel
®
Core i9/i7/i5 CPUs support up to 64GB
(32GB per DIMM)
Intel
®
Core i3/Pentium
®
/Celeron
®
CPUs
support up to 32GB (16GB per DIMM)
Socket 2 x SO-DIMM
VGA N/A
DVI N/A
LVDS
Dual Channel 24-bit, max resolution up to
1920x1200@60Hz
HDMI N/A
DisplayPort Max resolution up to 4096x2304@60Hz
MultiDisplay Triple Display
eDP Max resolution up to 4096x2304@60Hz
Ethernet
Ethernet 10/100/1000 Mbps
Controller 1 x Intel
®
I210, 1 x Intel
®
I219LM
