![ASRock IMB-A1000 Инструкция онлайн [6/38] 539679](/views2/1693521/page6/bg6.png)
6
* For detailed product information, please visit our website: http://www.asrockind.com
Rear I/O
VGA N/A
DVI N/A
HDMI N/A
DisplayPort 3
Ethernet 2
USB 6 x USB 3.1
Audio 1 (Mic-in, Line-out)
Serial N/A
PS2 N/A
Internal
Connector
USB 2 x USB3.0, 4 x USB2.0
LVDS/
inverter
N/A
eDP 1 (share with DisplayPort)
VGA N/A
Serial 2 x COM(RS-232/422/485)
SATA 3 x SATA3
Parallel N/A
GPIO N/A
SATA PWR
Output
1
Speaker
Header
1
TPM 1 x Onboard TPM 2.0 IC
Watchdog
Timer
Output From Super I/O to drag RESETCON#
Interval 256 Segments, 0, 1, 2, ...255sec
Power
Requirements
Input PWR ATX PWR 24+8-pin
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
Environment ATX: Press Button to PWR on
after Power input ready
Environment
Temperature 0ºC – 60ºC
Operating
Temp
-40ºC – 85ºC
