1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
AMD Ryzen Series-Raven Ridge (2200G, QC,
3.5GHz, 65W) (2400G, QC, 3.6GHz, 65W)
AMD Ryzen 3000-Matisse CPU, sku TBD, up to
TDP 95W
Chipset
AMD Promontory B450
Expansion
Slot
PCIe
1 x PCIe x16 (PCIe GEN III x8 for Raven Ridge
CPU) (PCIe GEN IV x16 for Matisse CPU)
M.2
1 x Key M (2242/2260/2280) with PCIe x4 and
SATA3 for SSD
1 x Key M (2242/2280) with PCIe x1 for SSD
1 x Key B (3042) with PCIe x1, USB 2.0 and
SIM Socket for 4G
1 x Key E (2230) with PCIe x1 and USB2.0 for
Wireless
Memory
Technology
Raven Ridge: Dual Channel DDR4 2933 MHz
Matisse: Dual Channel DDR4 3200 MHz
Max. 32 GB
Socket 2 x SO-DIMM
ECC
Support
N/A
Graphics
Controller
AMD Radeon™ Vega Series Graphics in Ryzen
Series APU (For Raven Ridge CPU)
VGA N/A
DVI N/A
LVDS N/A
HDMI N/A
DisplayPort
DisplayPort 1.2 with max resolution up to
4096x2160@60Hz
MultiDisplay Triple Display
eDP
eDP 1.4 (share with DisplayPort) with max
resolution up to 4096x2160@60Hz
Ethernet
Ethernet 10/100/1000 Mbps
Controller 2 x Intel
®
I210-AT
