8
1 : ATX 12V Power Connector
2 : PWR_BAT2
3 : Clear CMOS Header (CLRMOS2)
4 :
CPU FAN Connector (+12V)
5 : Clear CMOS Header (CLRMOS1)
6 : eDP Connector
7 : BL1, BL2
8 :
Chassis FAN Connector (+12V)
9 :
24-pin ATX Power Input Connector
10 : SATA Power Output Connector
11 : SATA3 Connectors (SATA3_1~3)
12 : USB 2.0 Headers (
USB2_4_5, USB2_6_7
)
13 : USB 3.0 Header (
USB3_16_17
)
14
:
System Panel Header
15 : COM Port Headers (COM3, 4) (RS232)
16 : COM Port PWR Setting Jumpers
PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
17 : M.2 Key-B Socket
(M2_KEYB1)
18 : ATX/AT Mode Select (PWR_JP1)
19 : LPC Header
20 : M.2 Key-E Socket (M2_KEYE1)
21 : Buzzer (BUZZ2)
22 : Chassis Intrusion Headers (CI1, CI2)
23 :
Front Panel Audio Header
24 : SPDIF Header
25 : M.2 Key-M Socket (M2_KEYM1)
Back Side :
M.2 Key-M Socket (M2_KEYM2)
SIM Card Socket (SIM1)
