18
2.4 Power Connectors
Please plug a power cable to the power connector.
4-Pin Power Connector
(4-pin DC12V1)
(see p.11, No. 7)
SATA Power Connector
(3-pin CPU_FAN1)
(see p.11, No. 23)
GND
+12V
GND
+5V
1
Please connect the SATA
Power cable to this connec-
tor.
