7
Internal
Connector
USB 2 x USB 2.0
Serial 1 x COM (RS-232/422/485)
SATA 1 x SATA3 (6.0Gb/s)
SATA PWR
Output
1
TPM 1 x Header
Watchdog
Timer
Output From Super I/O to drag RESETCON#
Interval 256 segments, 0,1,2…255sec
Power
Requirements
Input PWR 12V only (DC Jack)
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
Environment ATX: Press Button to PWR on
after Power input ready
Environment
Operating
Temp
0ºC – 60ºC
Storage
Temp
-40ºC – 85°C
