ASRock eDP-LVDS [2/2] Supported panel types

Supported Panel Types

Item

GPIO Setting

[GPIO3:GPIO2:GPIO1:GPIO0]

Panel Type Tested Panel Model

1 1111 1920x1080/24-bit/2-ch/LED M215HW01 VB

2 1110 1440x900/24-bit/2-ch/LED MT190AW02 V.4

3 1101 1024x768/24-bit/1-ch/CCFL M150XN07

4 1100 1280x1024/24-bit/2-ch/CCFL M170EG01 VD

5 1011 1366x768/24-bit/1-ch/CCFL M185XW01 V8

6 1010 1440x900/24-bit/2-ch/CCFL M190PW01 V7

7 1001

1024x600/18-bit/1-ch/LED

CLAA102NA2CCN

8 1000

800x600/18-bit/1-ch/CCFL

SJ084MA03

9 0111

1280x1024/24-bit/2-ch/LED

G170EG01 V1

10 0110

1024x768/24-bit/1-ch/LED

G150XG01.3

11 0101 1600x900/18-bit/2-ch/LED B173RW01 V0

12 0100 1366x768/24-bit/1-ch/LED CALL185WA04 M185XW01 VF

13 0011 1366x768/18-bit/1-ch/LED HSD121PHW1-A01

14 0010 800x600/24-bit/1-ch/LED G084SN05 V.8

15 0001 640x480/24-bit/1-ch/LED G065VN01V2

16 0000 1024x768/18-bit/1-ch/LED CLAA104XA02CW

*For the updated information, please visit www.asrockind.com.

*e Chrontel F/W only can be ashed via ASRock Industrial M/B.
