iBOX-Whiskey Lake/Ryzen
16 17
English
Internal
Connector
USB 2 x USB 2.0
LVDS/
inverter
N/A
eDP N/A
VGA N/A
Serial 1 x COM (RS-232/422/485)
SATA 1 x SATA3 ( 6.0Gb/s)
Parallel N/A
GPIO N/A
SATA PWR
Output
1
Speaker
Header
N/A
TPM N/A
Watchdog
Timer
Output N/A
Interval N/A
Power
Requirements
Input PWR 12V / 96W DC-In (DC Jack)
Power On
ATX Supported
ATX: Press Button to PWR on after Power
input ready
Environment
Operating
Temp
0ºC – 60ºC
Storage
Temp
-40ºC – 85°C
Rear I/O
VGA N/A
DVI N/A
HDMI 1
DisplayPort 2
Ethernet 2
USB 3 x USB 3.1
Audio 1 (Mic-in, Line-out)
Serial N/A
eSATA N/A
PS2 N/A
