General Outline ESIE10-01
1–138 Part 1 – System Outline
3
11
4
5
KT1-1 Delay Relay
KT1-2 Delay Relay
KT1-3 Delay Relay
KT13-1 Time Delay Relay
KT13-2 Time Delay Relay
KT13-3 Time Delay Relay
M1 Compressor 1
M2 Compressor 2
M3 Compressor 1
M101 Fan Motor
M102 Fan Motor
M103 Fan Motor
M104 Fan Motor
M105 Fan Motor
M106 Fan Motor
M107 Fan Motor
M108 Fan Motor
M109 Fan Motor
M110 Fan Motor
M201 Fan Motor
M202 Fan Motor
M203 Fan Motor
M204 Fan Motor
M205 Fan Motor
M206 Fan Motor
M207 Fan Motor
M208 Fan Motor
M209 Fan Motor
M210 Fan Motor
M301 Fan Motor
M302 Fan Motor
M303 Fan Motor
M304 Fan Motor
M305 Fan Motor
M306 Fan Motor
M307 Fan Motor
M308 Fan Motor
M309 Fan Motor
M310 Fan Motor
MOV.V Varistor
OAT Outside Air Temperature
OP-1 Oil Pressure Transducer Cir. 1
OP-2 Oil Pressure Transducer Cir. 2
OP-3 Oil Pressure Transducer Cir. 2
OPLA Low Ambient
OPLA Low Ambient
OPLA Low Ambient
OPLA Low Ambient
OPLA Low Ambient
OPLA Low Ambient
OPLA Low Ambient
OPPF Power Factor Correction
OPSP Single Pump
OPTP Twin Pump or Dual Pump
P1 Pump 1
P2 Pump 2
Q0 Unit On - Off
