ESIE10-01 The Digital Controller
Part 2 – Functional Description 2–21
3
2
4
5
1
Dynamic default
values
The fan staging dead bands have different default values based on the vfd enable set point. When the
vfd enable set point is changed, a set of default values for the fan staging dead bands is loaded as
follows:
VFD is enabled VFD is disabled
Set Point
Default
loaded
Set Point
Default
loaded
°C °C
Fan Stage Up Deadband 1 2.5 Fan Stage Up Deadband 0 4
Fan Stage Up Deadband 2 4 Fan Stage Up Deadband 1 5
Fan Stage Up Deadband 3 5 Fan Stage Up Deadband 2 5.5
Fan Stage Up Deadband 4 4 Fan Stage Up Deadband 3 6
Fan Stage Up Deadband 5 4 Fan Stage Up Deadband 4 6.5
Fan Stage Up Deadband 5 6.5
Fan Stage Down Deadband 2 4 Fan Stage Down Deadband 2 10
Fan Stage Down Deadband 3 3.5 Fan Stage Down Deadband 3 8
Fan Stage Down Deadband 4 3 Fan Stage Down Deadband 4 5.5
Fan Stage Down Deadband 5 2.5 Fan Stage Down Deadband 5 4
Fan Stage Down Deadband 6 2.5 Fan Stage Down Deadband 6 4
