Safety Cautions SiE-64
iv
Caution
Do not use the equipment in a place
filled with oily smoke such as a
kitchen or in a place filled with
combustible gas, corrosive gas or
metal dust.
Otherwise fire and equipment
malfunction can result.
Do not use in humid places or places
which might be wet, such as
bathrooms.
Contact with
water can lead to
electric shock or
damage the
equipment.
Select a sturdy wall or pillar when
mounting the equipment on a wall.
Do not use the equipment near a
lighting fixture (keep a distance of at
least 1 m).
Lighting equipment
can cause poor
reception of remote
controller signals
and equipment
discoloration.
Do not use outdoors or where
exposed to direct sunlight.
Direct sunlight can
weaken remote
control signal
reception sensitivity
and discolor the
casing.
Do not use near to sources of heat
such as heaters.
Heat can discolor and deform the
casing.
Keep the unit and remote control
minimum 1 m from lighting, TVs,
radios, stereos and aerials.
This unit can disturb TV
pictures and generate
interference. Illumination can
weaken remote control signal
reception sensitivity and discolor the
casing.
Keep the equipment 10 cm or more
away from the wall when used on a
table.
Otherwise the wall can become dirty.
Do not use in the place of kitchen
fans or cooker hood fans.
Adverse coditions of use can shorten
service-life of the prefilter and ion filter,
as well as lead to equipment damage.
Prevent combustibles (hair sprays,
etc.), sparks and incense from being
drawn into the unit.
Such substances can cause fire.
Do not insert fingers or objects into
the openings of the suction and
discharge grilles.
Otherwise
electrical shock
and equipment
malfunction can
result.
When used in conjunction with a
humidifier, keep mist from being
directly drawn into the unit.
Mists can lead to electric shock and/or
equipment damage.
Si-64.book Page iv Monday, June 18, 2001 2:57 PM
