3.5.3 Power Source
This page displays the PSU information. Please make sure that the PSU supports
PMBus.
Power Source Page
Power Supply Status: Displays the PSU status is normal or not.
AC Input Voltage: Displays the input voltage of the PSU.
AC Input Current: Displays the input current of the PSU.
DC 12V Output Voltage: Displays the output voltage of the PSU.
DC 12V Output Current: Displays the output current of the PSU.
Temperature 1: Displays the temperature 1 of the PSU.
Temperature 2: Displays the temperature 2 of the PSU.
Fan 1: Displays the fan speed 1 of the PSU.
Fan 2: Displays the fan speed 2 of the PSU.
DC 12V Output Power: Displays the output power of the PSU.
AC Input Power: Displays the input power of the PSU.
PWS Serial Number: Displays the serial number of the PSU.
3.6 Logs & Reports
3.6.1 IPMI Event Log
This page displays the list of event logs occurred by the different sensors on this
device. Double click on a record to see the details of that entry. You can use the
sensor type or sensor name filter options to view those specific events or you can
12
