ASRock EP2C621D8 [13/66] Fru information

System Inventory Page

Note:

1. The information will be refreshed when the system POST. Please restart the system if you see

nothing on screen.

2. The information on this page may differ by platforms, and this page may not be available for

certain platforms.

3.5.2 FRU Information

This page displays the FRU information. Select a FRU Device ID from the FRU

Information section to view the details of the selected device.

FRU Page
