Anti corrosion protection as standard
Standard anticorrosion protection with the hydrophilic gold n coating, giving the condenser coil a longer life span under corrosive
environment.
Cooling only
Indoor UnIT UAT150CGXY UAT180CGXY UAT240CGXY UAT300CGXY
Cooling capacity Nom. kW
43.96 (1) / 42.26 (2) / 39.21 (3) / 38.71 (4) 56.36 (1) / 54.25 (2) / 50.85 (3) / 49.765 (4) 74.74 (1) / 71.81 (2) / 67.409 (3) / 64.478 (4) 92.12 (1) / 87.92 (2) / 83.47 (3) / 81.565 (4)
Btu/h
150,000 (1) / 144,200 (2) / 133,800 (3) / 132,100 (4) 192,300 (1) / 185,100 (2) / 173,500 (3) / 169,800 (4) 255,000 (1) / 245,000 (2), 230,000 (3) / 220,000 (4) 314,300 (1) / 300,000 (2) / 284,800 (3) / 278,300 (4)
Power input Cooling Nom. kW 13.07 16.92 23.00 28.36
EER W/W 1.51 (4) 1.55 (4) 1.62 (4) 1.57 (4)
Btu/hr/W
11,5 (1) / 11,0 (2) / 10,2 (3) / 10,1 (4) 11,4 (1) / 10,9 (2) / 10,4 (3) / 10,0 (4) 11,1 (1) / 10,7 (2) / 10,0 (3) / 9,6 (4) 11,1 (1) / 10,6 (2) / 10,0 (3) / 9,8 (4)
Evaporator Air ow rate Cooling m/min 130.38 184.08 223.74 246.06
cfm 276,262 390,047 474,083 521,377
External static pressure (standard) Pa 125 150 200 250
Casing Colour Light grey
Evaporator piping connections
Condensation drain size
OD mm 25.40
Condenser Dimensions Unit
HeightxWidthxDepth
mm 1,390x1,965x1,630
1,690x1,965x1,905 1,650x2,410x2,030
Weight Unit kg 600 650 850 980
Casing Colour Light grey
Material -
Operation range Cooling Min.~Max. °CDB 19~54
Sound pressure level
Nom. dBA 66 68 73
Sound power level
Nom. dBA 85 87 92
Refrigerant Type R-22
Power supply Phase/Frequency/Voltage Hz/V 3N~/50/380-415
(1) Gross cooling capacity based on 26.7 °C DB/19.4 °C WB indoor and 35 °C DB outdoor (2) Cooling capacity based on ARI standard with condition 26.7 °C DB/19.4 °C WB indoor and 35 °C DB outdoor (3) Gross cooling capacity based on 26.7 °C DB/19.4 °C WB
indoor and 46 °C DB outdoor (4) Gross cooling capacity based on 26.7 °C DB/19.4 °C WB indoor and 48 °C DB outdoor (5) Gross capacity does not include the eect of evaporator fan motor heat (6) All specications are subjected to change by the manufacturer
without prior notice. (7) Cooling: indoor temp. 27°CDB, 19°CWB; outdoor temp. 35°CDB, 24°CWB (8) All units are being tested and comply to ISO5151. (9) Sound pressure levels are according to JIS B 8615 standard. Position of the measurement is 1m in front
and 1m below the unit. (10) Designation based on cooling cycle.
Quiet operation as standard
The operating sound level is down to 66 dBA.
Easy duct design
Horizontal air discharge from the top and return air from the bottom for an easy duct design.
*** Mechanical control rooftop series name is UAT-CGXY9.
Rooftop unit Thermostat
Evaporator fan Dry contact input G (fan)
Comp 1 Dry contact input Y1 (Cooling 1)
Comp 2 Dry contact input Y2 (Cooling 2)
24 VAC 24 VAC
Flexible control: optional mechanical control series
For certain applications a mechanical control is required instead of PCB control. For the UAT-CGY series this is available through an optional
series***. The rooftop with mechanical control provides connection to the thermostat for control of evaporator fan motor, compressors
and condenser fan motor, and has a 24 Volt transformer provided for eld installed thermostat.
Separate service panel
Service panels are divided into two dierent sections for ease of servicing. Preliminary servicing & Troubleshooting can be conducted
by opening the top service panel, without stopping the unit operation.
