Daikin UAT180CGXY1 [7/8] Cooling only

High eciency

Nominal EER up to 3,08 W/W (10,5 Btu/hr/W)

Partial loading

The 2 compressors systems can run at part load when less

capacity is required.

Field convertible return and

supply air increases exibility

of installation*

The return and discharge air ow can be shifted to vertical

Btu/h 58,999.347 80,001.081 99,999.645 115,999.179 328,998.732 404,001.025

Power input Cooling Nom. kW 5.61 (1) 8.10 (1) 10.50 (1) 11.56 (1) 39.87 (1) 46.80 (1)

EER W/W 3.08 (1) 2.89 (1) 2.79 (1) 2.94 (1) 2.42 (1) 2.53 (1)

Btu/hr/W

10.52 9.88 9.52 10.03 8.25 8.63

Evaporator Air ow rate Cooling m/min 51 80 100 102 312 354

cfm 1,801 2,825 3,532 3,602 11,018 12,502

External static pressure (standard) Pa 98 294

Evaporator piping connections

Condensation

drain size

OD mm 25.4

Condenser Dimensions Unit

HeightxWidthxDepth

mm 1,000x1,100x1,530 1,000x1,300x1,530 1,974x2,252x3,180

Power supply Phase/Frequency/Voltage Hz/V 3~/50/380-415

(1) Cooling: indoor temp. 27°CDB, 19°CWB; outdoor temp. 35°CDB, 24°CWB (2) All units are being tested and comply to ISO5151. (3) All specications are subjected to change by the manufacturer without prior notice. (4) Sound pressure levels are according to

JIS B 8615 standard. Position of the measurement is 1m in front and 1m below the unit. (5) Designation based on cooling cycle.

1. horizontal throw 2. down throw

* available on UAT320AY1
