ESIEN05-04 Disassembly and Maintenance
Part 5 – Disassembly and Maintenance 5–7
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
B1 Heat exchanger assy E25 Fan motor
B1.1 Distributor with filter F1 Casing assy
B1.2 Single union joint F6 Inspection cover assy
B1.3 Single union joint F8 Drain pan assy
B1.4 Flare nut F8.1 Drain plug
B1.5 Flare nut F9 Sound absorbing material
C1 Fan rotor (turbo) F10 Heat exchanger blind plate assy
C2 Lock washer F11 Heat exchanger mounting plate
C3 Nut with washer F12 Hold plate assy
E1 Switch box assy F13 Panel mounting plate
E2 Switch box body F14 Drain pump mounting plate
E4 Bell mouth F15 Vibration isolator
E5 Switch box cover assy 1 F16 Hexagon mounting bolt
E6 Switch box cover 2 F17 Vibration isolator
E7.1 PCB assy F18 Nut with washer
E7.1.1 Thermistor (Air) F19 Feeler bulb clamp
E9 Capacitor F21 Rubber bush
E10 Terminal F22 Inner heat insulator
E11 Terminal block G1 Drain hose
E12 Power supply transformer G2 Hose band
E14 Wire harness H1 Top tray assy
E15 Wire harness H2 Bottom tray assy
E16 Wire harness K1 Drain hose assy
E19 Earth wire K2 Hose band
E20 Earth screw K3 Insulation for joint (liquid)
E21 Thermistor (liquid) K4 Insulation for joint (gas)
E23 Drain pump K5 Sealing material
E24 Float switch
