Specifications ESIEN05-04
1–54 Part 1 – System Outline
3
11
4
5
2.10 FDEQ – B
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FDEQ71B7V3B FDEQ100B7V3B FDEQ125B7V3B
Heat exchanger Rows x stages x fin pitch 3 x 14 x 1.75 mm
Face area 0.226 m² 0.344 m²
Tube type Hi-XSS diam. 7
Fin type Rhombus
Fan Air flow rate cooling (high) 16.0 m³/min 24.0 m³/min 30.0 m³/min
Air flow rate cooling (low) 12.0 m³/min 17.0 m³/min 20.0 m³/min
Air flow rate heating (high) 19.0 m³/min 28.0 m³/min 35.0 m³/min
Air flow rate heating (low) 14.0 m³/min 20.0 m³/min 24.0 m³/min
Qty x model (rotor)
2 x QD18G3BM
2 x QD18G2AM
1 x QD18G2BM
Qty x model (motor) MLA6027 MLA6028 A37P225E23
Fan speed 2 steps, direct drive
Fan type Sirocco
Refrigerant Type R410A
Safety and functional devices
Fan motor thermal fuse: 152
+/-2
°C
Air filter Resin net (with mold resistant)
Temperature control Computerized control
Weight Unit 38.1 kg 48.6 kg
Specification FDEQ71B7V3B FDEQ100B7V3B FDEQ125B7V3B
Unit Phase 1~
Voltage 230 V
Frequency 50 Hz
Power consumption 150 W 195 W 415 W
Nominal running current _
Fan motor FLA (Full load amps) _
No. of motors x output 1 x 130 W 1 x 155 W 1 x 225 W
