Griven RUBY MC R [22/32] Setting operating mode

5.1 Setting operating mode

By using the infrared remote control AL1321 it is possible to select one of the following operating mode.

• using DMX512 signal control mode

Each fixture is controlled from DMX512 signal control.

• MASTER-SLAVE or AUTOMATIC mode

The projector operates independently, without DMX512 signal control.

(see chapter 6.0 MASTER/SLAVE and AUTOMATIC function)

• using FIXED COLOURS mode (ONLY RGBW and DW)

The projector operates independently, without DMX512 signal control.

It is the first procedure to be performed. After pushing the buttons 1, 2, 3 it is pos-

coming from the projector.

The logout is automatic after 5 minutes of missing reception of the signal coming

from the remote control. Once th projector logs out it is not possible to perform

any other operation before a new login.

of DMX

mode

Select the nuber of DMX channels. If the setting is correct then the projector will

confirm the procedure by performing 2 white flashes. (e.g. Projector RGBW 5

channels, press 5)

The new entered address must feature 3 digits (e.g. 0 6 7). If the address is correct

then the projector will confirm the procedure by performing 3 white flashes
