MEAN WELL HVGC-240-1050A Datasheet онлайн
240W Constant Current Mode LED Driver
HVGC-240 series
■ Description
HVGC-240 series is a 240W LED AC/DC LED power supply featuring the constant current mode and high
voltage output. HVGC-240 operates from 180 528VAC and offers models with different rated current ranging~
between 700mA and 3500mA. Thanks to the high efficiency up to 93.5%, with the fanless design, the entire
series is able to operate for -40 ~ +90 case temperature under free air convection. The design of metal℃℃
housing and P67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications.I
HVGC-240 is equipped with various function options, such as dimming methodologies, so as to provide
the optimal design flexibility for LED lighting system.
LED street lighting
LED high-bay lighting
Parking space lighting
LED fishing lamp
Type HL for use in Class , Division 2Ⅰ
hazardous (Classified) location.
■ Features ■ Applications
IP65
IP67
Wide input range 180 ~ 528VAC
Constant Current mode output
Metal housing with Class designⅠ
Built-in active PFC function
IP67 / IP65 design for indoor or outdoor installations
Function options: output adjustable via potentiometer;
3 in 1 dimming (dim-to-off) ; Smart timer dimming
Typical lifetime>50000 hours
5 years warranty
File Name:HVGC-240-SPEC 2018-10-18
Type
A
B
IP Level
IP65
IP67
Io adjustable through built-in potentiometer.
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
Function Note
In Stock
In Stock
■ Model Encoding
- 1750HVGC - 240
A
Rated output current(700/1050/1400/1750/2100/2800/3500mA)
Rated wattage
Series name
Function options
Dx
D2
IP67
IP67
Built-in Smart timer dimming function by user request.
Built-in Smart timer dimming and programmable function.
By request
By request
Type HL
AB IP65
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
Io adjustable through built-in potentiometer &
In Stock
M M
110
