240W Constant Current Mode LED Driver
HVGC-240 series
File Name:HVGC-240-SPEC 2018-10-18
OUTPUT LOAD vs TEMPERATURE(Note.7)
AMBIENT TEMPERATURE,Ta ( )℃ Tcase ( )℃
LOAD (%)
(HORIZONTAL)
-40-250 204555657590
20
40
60
80
100
LOAD (%)
-40 -25 -10 0 15 30 50 55 60 65 70
20
40
60
80
100
(HORIZONTAL)
180VAC
230VAC
Above 277VAC
PF
LOAD
STATIC CHARACTERISTIC
TOTAL HARMONIC DISTORTION (THD)
POWER FACTOR (PF) CHARACTERISTIC
EFFICIENCY vs LOAD
HVGC-240 series possess superior working efficiency that up to 93.5% can
be reached in field applications.
※ 700mA Model, Tcase at 80℃
※ 700mA Model, Tcase at 80℃
EFFICIENCY(%)
LOAD
※ Tcase at 80℃
THD(%)
LOAD
INPUT VOLTAGE (V) 60Hz
180 347 480 528
100
90
80
70
60
50
40
440
LOAD (%)
(240W)
