•VRV
®
Systems • Indoor Units
143
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
6 Dimensional drawing & centre of gravity
6 - 2 Centre of gravity
FXMQ-P
4D060438
MODEL NAME
FXMQ40P
FXMQ50•63•80P
FXMQ100•125P
